The five axis reciprocating spraying machine with air spraying
system will help you get a good coating film and reduce the manual
cost. The details of automatic five axis spraying machine are as
follows.
1. This machine is widely used in many industry. Generally speaking
, standard type of this machine has two product tray. If you want
to buy a machine with four product tray, then you will get double
yield under the premise of high quality coating.
2. It is easy to debug the machine. You can finish debugging for
usual product in 15 minutes. The program writing of machine is
regard one plane of product as a program segment. When you finish
setting the start point , end point and the spraying speed, then
you have finished a program segment. After finish every program of
plane, then the complete program is finished.
3.This machine has continuous spraying method and step spraying
method.
4.The atomization and sector, painting output of spray gun can be
controlled by computer. When the machine begin to spray , the spray
gun can blow, in order to blow dust.
5.It is easy to use this machine ,and you can store 160 programs of
product. The machine operated by fully digital computer.
Technical characteristics:
1.Rotation speed:10-50rpm
2.Workpiece size: 600mm*600mm
3.Production:depending on the workpiece
4.Number of spray gun:1 pieces
5.Spraying method:theworkpiece rotates 90 degrees, the spray gun extends the XY axis
direction spraying
6.XYReciprocating speed: servo motor drive 01.5m/sec
7.XYaxis travel1200*1000
8.Lance angle: automatic adjustment
9.Control mode: touch screen input data, with programmable PLC
central control box
Technical advantages
1.Wide range of applications, strong applicability, high quality
and high efficiency spraying
3.CNC servo drive, reciprocating speed, and accurate positioning
4.All Chinese menu, easy to learn, you can write multiple sets of
programs, intelligent storage system, program settings and free
movement, you can store 30 sets of programs
5.The frame is modular, easy to move and easy to maintain
Product Details
Application:
The five axis automatic spraying reciprocating machine is wildly
used in the field of plastic, electronics,hardware handicraft, TV
shell,computer panels,glass,toys, woodwork,magnet ring etc, also
suit for large flat parts(such as door,glass) etc precision surface
spraying. The spraying process can reach the surface spraying or
multi-surface spraying. Multi-axis linkage spraying or one axis
reciprocating movement is OK. The parameter is adjustable
flexible.the programming is convenient and fast.
Our Service
Our products are widely used in surface treatment of automobiles
and auto parts, household
appliances, medical equipment, metal products, construction
machinery, mechanical and
electrical products, motorcycles and other metal products, wooden
furiture, plastic products
and other types of products.
After-sales:
1.We will send the engineers for onsite installation, commissioning
and operation training.
2.We will provide fault handing service and lifetime warranty.
3.We provide 1 year warranty for each machine.
4.We will contact you back periodically to learn machine conditions.
5.We also provide the service for further extension on your existing
machine.
Shenzhen Songqi robot automation equipment limited company is
national high and new technology industry and has a number of
invention patents and utility new patents. Our company is Japanese
Kawasaki, Yaskawa robot partner in Southern China. Company early
(2005-2010) is Tianwei mechanical and Electrical Equipment Co.,
Ltd., mainly engaged in automatic reciprocating spraying machine,
coating automatic line, non-standard coating equipment and so on
.With the further establishment of the market and the continuous
improvement of the cost of labor in China, automation is more and
more popular with the vast number of users. In this market
environment, in order to better integrate the company resources,
the company retains the company's reciprocating spraying machine
project of Tianwei, deep manage robot applications, such as robot
spraying, robot palletizing, robot handling, robot stamping,
automatic transplanting etc.
